Fact sheet


This fine-grained volcanic rock has a similar composition to basalt, but the oligoclase composition plagioclase feldspar and presence of orthoclase, a potassium rich feldspar, mark it as unusual. The sample comes from a suite of Lower Carboniferous alkaline volcanic rocks in the Scottish Borders, similar in age and composition to others in the Midland Valley of Scotland further north. This sample is from Mellerstain Hill quarry, near Kelso.

In thin section the rock contains olivine phenocrysts altered to chlorite and clay minerals along cracks, grey-pink pyroxene phenocrysts, small orthoclase feldspar phenocrysts and compositionally zoned plagioclase, and some phenocrysts showing almost sieve-like resorption textures. The groundmass comprises plagioclase, pyroxene, olivine and iron oxides.

Additional images
  • Mugearite hand specimen close up
  • Mugearite hand specimen
55.6477, -2.5736
The Mellerstain Hill quarry, near Kelso, Berwickshire
About this collection

The United Kingdom Virtual Microscope (UKVM) collection consists of igneous, sedimentary and metamorphic rocks from around the UK.

It is intended as a teaching resource, helping to tell the story of the common rock types and how they form, and reflecting the history of the UK at the margins of the continent of Europe. The collection is a series of teaching sets, for example igneous rocks from the North Atlantic Igneous Province and SW England; high-temperature metamorphic rocks from Scotland and low-temperature metamorphic rocks from Wales; and sedimentary rocks, including English limestones and sandstones.

Sample details

Rock-forming mineral
Accessory minerals
iron oxide
Category guide
Category Guide
Refers to any word or phrase that appears in the individual rock names. Names are generally descriptive; they allow users to search for broad terms like ‘granite’ as well as more specific names such as ‘breccia’. However, the adjacent descriptions of the specimens captures a wider range of general words and phrases and is a more powerful search tool.
Refers to any word or phrase that appears anywhere in the descriptions of the specimens
Accessory minerals
Minerals that occur in very low abundance in a rock. They are usually not visible with the naked eye and contribute perhapssver, they often dominate the rare elements such as platinum group metals.
Rock-forming minerals
Minerals that make up the bulk of all rock samples and are also the ones used in rock classi?cation.
Selecting one or more period, for example 'Jurassic'.
A term used to group together related samples that are not already gathered into a single Collection. For instance, there is a ‘SW England granites’ theme that includes such rock types as granite, hydrothermal breccia, skarn and vein samples.
A general term used to label a rock sample. It is a useful way of grouping similar samples throughout a collection. Category names are often, but not exclusively, common rock names (e.g. granite, basalt, dolerite, gabbro, greisen, skarn, gneiss, amphibolite, limestone, sandstone).
